Powerful 4K and Full HD imagery
A 1/2.3-inch type 4K/UHD CMOS Sensor with a DIGIC DV6 image processor captures detailed footage up to 4K 30P at 4:2:2/10-bit. Video can be output in Enhanced Full HD which benefits from 4K over sampling.

Versatile, high quality 20x optical zoom
CR-X300 has a 20x optical zoom lens with a focal length range of 29.3–601mm (35mm equivalent) in UHD as well as the option of a 20x Digital zoom. The CR-X300 also features Canon’s 4 Axis IS system for enhanced stability when shooting.

Advanced streaming and output options
The CR-X300 is highly flexible thanks to its 6G SDI and HDMI outputs, PoE++ as well as network connectivity that supports protocols such as Canon XC, RTP/RTSP, RTMP/RTMPS, SRT, FreeD and NDI|HX video transmission plus standard communication, streaming protocols and control protocols.

Hybrid AF for precise focus
The CR-X300 combines high-precision contrast AF with high-speed phase-detection AF, ensuring accurate focus of the subject, even in low light.

Smooth, precise control
The CR-X300 is capable of simultaneous high precision Pan, Tilt and Zoom as slow as 0.3deg/sec, even with pre-sets, and is compatible with Canon’s RC-IP100 controller, Remote Camera Control Application plus selected third-party options.

For various lighting conditions
The CR-X300 is equipped with an internal 1/8 graduated type ND filter with the option to attach a 1/32 Enhanced ND filter mechanism that inserts a filter on the front surface of the lens unit, extending the ND range from 1/32 to 1/256.

Custom picture settings
The CR-X300 features a custom picture menu which allows for fine tuning of image settings in a wide range of shooting scenarios with other cameras such as Cinema EOS, for efficient workflow in a multi camera setup.

Robust and durable body
Rated IP65 water and dust resistant with additional salt repellence to perform from -15° to +40°C and in 90% humidity, the fully sealed body also features an inbuilt wiper for a clear view.

Seamless High Quality 4K Video Streaming
With the free of charge1 Webcam Driver2, you can enjoy seamless video streaming in up to 4K 30p with maximum 5 selected Canon PTZ Cameras3 via a simple ethernet connection. Compatible with most conferencing platforms and applications which require UVC, this Windows OS software is a virtual USB driver which allows an easy video streaming integration, ideal for video conferencing and online lectures.

1. A third party license may be required
2. Software available in June 2022
3. Applicable only to the CR-N500, CR-N300 and CR-X300

Specifications

4K UHD
1/2.3-inch type sensor for stunning quality

20x optical zoom
35mm equivalent focal length of 29.3mm – 601mm (UHD only) plus an additional 20x digital zoom in FHD

DIGIC DV6 Image Processor
Powerful image processing to capture in that can capture) up to 4K 30P at 4:2:2/10-bit

Support for wide range of Protocols
RTMP, NDI|HX, RTP/RTSP, RTMPS Canon XC Protocol and Standard Communications Protocol

Hybrid AF
For fast and accurate focusing even in low light

IP65 rated
Water and dust resistant weather sealing
